| Electrical | |
| Impedance | 75Ω |
| Frequency Range | 0 - 3GHz |
| Working Voltage | 250Vrms |
| Dielectric Withstanding Voltage | 750Vrms |
| Reflection Factor (VSWR) | 1.13 (max) DC - 1.5GHz 1.29 (max) 1.5 - 3GHz |
| Contact Resistance | Centre contact 4.0mΩ Outer contact 2.5mΩ |
| Insulation Resistance | 1000MΩ |
| Connector Type | Female |
| Material | |
| Metal Parts | Brass / Au |
| Centre Pin | BeCu / 10µ Au |
| Insulators | PTFE |
| Environmental | |
| Temperature Range | -65 to +85°C |
| Mechanical | |
| Mating Cycles | 500 |
| Processing | |
| Processing | Maximum wave and hand soldering temperature 265°C |
| General Information | |
| Mounting Type | Top Entry |
| Leg Length | 2.7mm |
| Hardware | Supplied with 2 slot nut |
